Thick Sheet Vacuum Forming Machine for Bathtubs
PDVF-ML2015 is a complete technical analogue of the Italian vacuum forming line COMI GROUP SuperLine NG PF2 in terms of technical characteristics, functions, and purpose.
PDVF-ML2015 is a complete technical analogue of the Italian vacuum forming line COMI GROUP SuperLine NG PF2 in terms of technical characteristics, functions, and purpose.
Next: No more data
Product Details
▎BASIC PARAMETERS
All Pudi Machinery vacuum forming machines can be customised to meet customer requirements.
|
Model |
Molding size (L* W * H) |
Total power |
Dimension (L*W*H) |
Production Speed |
|
PDVF-ML2015 |
2000*1500*500mm |
220kw(Actual use30%-70%) |
3800*4200*3800mm |
2～7 minutes/Pc (2~6 mm) |
▎MACHINE DETAIL IMAGES
 |
 |
 |
 |
▎FUNCTIONAL FEATURES
|
Aplicable Materals |
ABS, PS, PE, PC, PP, PVC, PET, PMMA composite materials, alloy materials, and other thermoforming sheets. |
|
Molding Thickness |
1-15mm |
|
Drving method |
Servo Motor |
|
Heating method |
Stype infrared heating tube |
|
Computer operating system window |
Universal Wellhead Plate (or Integrated Fixture) |
|
Coolngsystem |
Powerfulfan and spray |
|
Mold release system |
Multi-stage mold release system |
|
Blowing Bubble Ant-Sag |
Automatic infrared sensing |
|
Data storage function |
200 sets of data can be stored |
|
Vacuum system |
Two-stage vacuum system |
|
Safety system |
Pressureframe anti-dropand grating protection system |
|
Operation |
Manual loadingandunloading |
|
Other Functions |
Mold core extraction,mold cavity heat exhaust device |
▎MAIN COMPONENTS
Over 90% of the electrical components in this equipment are sourced from internationally renowned brands.
|
NO |
Name |
Brand |
|
1 |
PLC/HMI |
Siemens |
|
2 |
Intermediate Relay |
Omron (Imported) |
|
3 |
Temperature Control Regulator |
AOYI Digital Regulator |
|
4 |
Vacuum Pump |
Busch (Germany) |
|
5 |
Solenoid Valve |
SMC (Imported) |
|
6 |
Contactor |
Schneider (Imported) |
|
7 |
Circuit Breaker |
Schneider (Imported) |
|
8 |
Proximity Switch |
Omron (Imported) |
|
9 |
Cylinder |
SMC (Imported) |
|
10 |
Push Button Switch |
Schneider (Imported) |
|
11 |
Electric Furnace Motor |
Siemens |
|
12 |
Driver |
Siemens |
|
13 |
Upper Mold Servo Motor |
Siemens |
|
14 |
Lower Mold Servo Motor |
Siemens |
|
15 |
Manipulator |
Siemens |
|
16 |
Bearing |
C&U Bearing |
|
17 |
Heating Tube |
Pudi Self-developed |
|
19 |
Air Switch |
Siemens |
▎AVAILABLE PRODUCTS
It is used for the production of bathtubs.
▎OUR EXPERTISE, YOUR ADVANTAGE
1. Professional Technical Team:20 years of R&D and production experience, with rich experience in vacuum moulding technology
2. Non-standard customized service: Provide one-stop service to provide customers with excellent, complete vacuum forming solutions.
3. Quality assurance and reliability: All mechanical parts are produced independently by the CNC machining centre
4. Worry-free after-sales service: Integration of installation, commissioning and training services
 |
 |
 |
 |
 |
 |
